Technical realization elements of adjustable illuminance refrigerated and fresh-keeping experiment cabinet

Technical realization elements:

4. The purpose of the present utility model is to provide an adjustable illuminance refrigeration and fresh-keeping experiment cabinet to solve the above-mentioned problems in the background art.

5. In order to achieve the above purpose, the present utility model provides the following technical solutions:

6. An adjustable illuminance refrigerating and fresh-keeping experiment cabinet, comprising a cabinet body, the top of the cabinet inner wall is correspondingly equipped with an illuminance lamp, and a number of storage boards are arranged inside the cabinet. Movable connection, the top of the cabinet is connected with the adjustable control box. The front surface of the control box is equipped with a display screen at the center of the front surface. There are several adjustment switches on both sides of the display screen. The front surface is provided with a number of heat dissipation holes to accelerate the heat dissipation speed, and the front surface of the cabinet body is movably connected with a cabinet door.

7. As a further solution of the utility model: a push plate is arranged inside the mounting seat, one end of the mounting seat away from the inner wall of the storage plate is fixedly connected to one end of the spring, the other end of the spring is connected to one side of the push plate, and both ends of the storage plate are connected to the mounting block , The end of the mounting block away from the storage plate is attached to the side of the push plate away from the spring.

8. As a further solution of the present utility model: the bottom of the cabinet is equidistantly provided with a number of first through holes, the inside of the first through hole is provided with a first refrigeration fin, the top of the refrigeration box is equidistant with a number of second through holes, the first A second cooling fin is arranged inside the two through holes, and the second through hole is matched with the first through hole.

9. As a further solution of the utility model: a dual-axis motor is installed at the bottom center of the inner wall of the refrigeration box through a fixed platform, the output ends of the dual-axis motor are connected with one end of the threaded rod, and the end of the threaded rod is away from the dual-axis motor and the refrigeration box The two sides of the inner wall are rotatably connected. The outer wall of the threaded rod is sleeved with a first bevel gear, the first bevel gear is meshed with the second bevel gear, the second bevel gear is sleeved on the outer wall of the rotating rod, and the top of the rotating rod is connected with the fan input end. The bottom of the rod is rotatably connected with the bottom of the inner wall of the refrigeration box.

10. As a further solution of the present utility model: one end of the threaded rod away from the biaxial motor is rotatably connected to both sides of the inner wall of the refrigerating box through a bearing, two bearings are provided, and the two bearings are arranged at corresponding positions on both sides of the inner wall of the refrigerating box.

11. As a further solution of the utility model: the front surface of the display screen is provided with a waterproof membrane to prolong the service life.

12. As a further solution of the present utility model: the front surface of the cabinet door is provided with a handle which is convenient for the staff to open and close.

13. Compared with the prior art, the beneficial effects of this utility model are:

14.1. When the present invention needs to store the experimental objects, the staff can put the objects inside the storage board. In order to facilitate the adjustment of the illuminance lamp, the staff can adjust the illuminance of the illuminance lamp by adjusting the switch, and the set display screen is convenient The staff read the number of the illuminance lamp, which is easy to adjust, and meets the needs of various illuminances. In order to improve the refrigeration effect of the experimental cabinet, the dual-axis motor is started. The dual-axis motor can drive the threaded rod to rotate and set it on the thread. The first bevel gear on the outer wall of the rod can rotate coaxially, while the first bevel gear rotates, it can drive the second bevel gear meshing with it to rotate. The rotating rod provided on the inner wall of the second bevel gear can rotate. At the same time, it can drive the fan to work, and at the same time energize the first cooling plate and the second cooling plate, the wind blown by the fan can be blown into the cabinet through cooling, which can effectively improve the working efficiency of the experimental cabinet and meet the needs of the staff. .

15.2. In the present utility model, when the storage board needs to be replaced, the staff can move to the inside of the installation seat through the installation block, the installation block can push the push plate to move inside the installation seat, and the push plate can move while squeezing the spring. The one on one side can fall off from the inside of the mounting seat to realize the disassembly of the storage board, which is convenient for the staff to disassemble quickly, and has simple operation, convenient use and strong practicability.
